Megger SWG 505 – Cable Fault Locator

• Integrated TDR, surge wave generator, and arc reflection for complete fault location
• Surge output up to 5 kV for effective fault detection and tracing
• Designed for low and medium voltage cable systems
• Supports pre-location, route tracing, and pinpointing of faults
• Clear interface with guided operation for efficient testing
• Compact, rugged design for field deployment

The Megger SWG 505 Cable Fault Locator delivers a focused and efficient approach to cable fault location. It combines TDR, surge wave generation, and arc reflection in one integrated unit, which allows technicians to locate faults with greater speed and accuracy. The system provides surge output up to 5 kV, helping detect and trace faults in low and medium voltage cables. It supports pre-location, route tracing, and pinpointing, which improves overall fault location precision. The interface remains clear and easy to use, which helps reduce setup time in the field. Its compact and rugged design also makes it well suited to demanding site conditions. Overall, the SWG 505 helps engineers identify faults quickly and restore service with confidence.
